5–2
1
Chapter 5: Board Update Portal
Using the Board Update Portal to Update User Designs
You can click Stratix IV E FPGA Development Kit on the Board Update
Portal web page to access the kit’s home page for documentation updates
and additional new designs.
f You can also navigate directly to the Stratix IV E FPGA Development Kit page of the
Altera website to determine if you have the latest kit software.
Using the Board Update Portal to Update User Designs
The Board Update Portal allows you to write new designs to the user hardware
portion of flash memory. Designs must be in the Nios II Flash Programmer File
( .flash ) format.
1
1
Design files available from the Stratix IV E FPGA Development Kit page include
.flash files. You can also create .flash files from your own custom design. Refer to
“Preparing Design Files for Flash Programming” on page A–2 for information about
preparing your own design for upload.
To upload a design over the network into the user portion of flash memory on your
board, perform the following steps:
1. Perform the steps in “Connecting to the Board Update Portal Web Page” to access
the Board Update Portal web page.
2. In the Hardware File Name field specify the .flash file that you either downloaded
from the Altera website or created on your own. If there is a software component
to the design, specify it in the same manner using the Software File Name field,
otherwise leave the Software File Name field blank.
3. Click Upload . The progress bar indicates the percent complete.
4. To configure the FPGA with the new design after the flash memory upload process
is complete, set the PGM CONFIG SELECT rotary switch (SW5) to the 1 position
and power cycle the board, or press the RESET CONFIGn button (S1).
As long as you don’t overwrite the factory image in the flash memory device, you can
continue to use the Board Update Portal to write new designs to the user hardware
portion of flash memory. If you do overwrite the factory image, you can restore it by
following the instructions in “Restoring the Flash Device to the Factory Settings” on
page A–4 .
Stratix IV E FPGA Development Kit User Guide
June 2011 Altera Corporation
